Secure Boot - Confirm Enabled or Disabled in Windows 8
This tutorial will show you how to confirm if Secure Boot is enabled or disabled in your UEFI settings from inside Windows 8 and 8.1.
Published by Brink
#1
ByLine
How to Check if Secure Boot is Enabled or Disabled in Windows 8 and 8.1
Synopsis
This tutorial will show you how to confirm if Secure Boot is enabled or disabled in your UEFI settings from inside Windows 8 and 8.1.
How to Check if Secure Boot is Enabled or Disabled in Windows 8 and 8.1

information   Information
This tutorial will show you how to confirm if Secure Boot is enabled or disabled in your UEFI settings from inside Windows 8 and 8.1.

You must be signed in as an administrator to be able to do the steps in this tutorial.

Note   Note
UEFI (replaces BIOS) has a firmware validation process, called secure boot, which is defined in Chapter 27 of the UEFI 2.3.1 specification. Secure boot defines how platform firmware manages security certificates, validation of firmware, and a definition of the interface (protocol) between firmware and the operating system. Secure boot prevents “unauthorized” operating systems and software from loading during the startup process.

Quick summary

  • UEFI allows firmware to implement a security policy
  • Secure boot is a UEFI protocol not a Windows 8 feature
  • UEFI secure boot is part of Windows 8 secured boot architecture
  • Windows 8 utilizes secure boot to ensure that the pre-OS environment is secure
  • Secure boot doesn’t “lock out” operating system loaders, but is a policy that allows firmware to validate authenticity of components
  • OEMs have the ability to customize their firmware to meet the needs of their customers by customizing the level of certificate and policy management on their platform
  • Microsoft does not mandate or control the settings on PC firmware that control or enable secured boot from any operating system other than Windows

For more information about secure boot, see:



EXAMPLE: Secure Boot in your UEFI firmware settings at boot






OPTION ONE
To Check if Secure Boot is Enabled or Disabled in System Information

1. Press the :winkey: + R keys to open the Run dialog, type msinfo32, and press Enter.​
2. In the right pane of System Summary in System Information, see what the Secure Boot State value is. (see screenshot below)​

Value

Description

On

PC supports Secure Boot and Secure Boot is enabled

Off

PC supports Secure Boot and Secure Boot is disabled

Unsupported

PC does not support Secure Boot or is a Legacy (BIOS) installed Windows








OPTION TWO
To Check if Secure Boot is Enabled or Disabled in PowerShell

1. Open an elevated PowerShell window from inside Windows 8 or 8.1.​
2. If prompted by UAC, then click/tap on Yes.​
3. In the elevated PowerShell window, copy and paste the command below, and press Enter.​
Confirm-SecureBootUEFI

4. Based on what the cmdlet returns, this will let you know if Secure Boot is enabled or disabled in your UEFI settings.​

Cmdlet Return

Description

True

PC supports Secure Boot and Secure Boot is enabled

False

PC supports Secure Boot and Secure Boot is disabled

Cmdlet not supported on this platform

PC does not support Secure Boot or is a Legacy (BIOS) installed Windows






That's it,
Shawn



Last edited by a moderator:

My Computer

System One

  • OS
    64-bit Windows 10
    Computer type
    PC/Desktop
    System Manufacturer/Model Number
    Custom self built
    CPU
    Intel i7-3930K 3.2 Ghz (O/C to 4 Ghz)
    Motherboard
    ASRock X79 Extreme11
    Memory
    32 GB (8GBx4) G.SKILL DDR3 Quad PC3-19200 2400 MHz
    Graphics Card(s)
    ASUS ROG-STRIX-GTX1080TI-O11G-GAMING
    Sound Card
    SB Recon 3Di Integrated Chip
    Monitor(s) Displays
    3 x 27" Asus VE278Q
    Screen Resolution
    1920x1080
    Hard Drives
    256GB OCZ Vector
    6TB WD Black WD6001FZWX
    PSU
    OCZ Series Gold OCZZ1000M 1000W
    Case
    Corsair Air 740
    Cooling
    Corsair Hydro H115i
    Keyboard
    Logitech wireless K800
    Mouse
    Logitech MX Master
    Internet Speed
    100 Mb/s Download and 10 Mb/s Upload
    Browser
    Internet Explorer 11
    Antivirus
    Malwarebyte Anti-Malware Premium
    Other Info
    Lite-On iHBS212 12x BD Writer
    Creative F200 webcam
    Samsung CLX-3175FW Printer
    Linksys EA9500 Router
    Arris SB6190 Cable Modem
    APC SMART-UPS RT 1000 XL

theog

VIP Member
VIP Member
Gold Member
Posts
5,591
#2
Nice one, Shawn.


My Computer

System One

  • OS
    ME, XP,Vista,Win7,Win8,Win8.1
    Computer type
    PC/Desktop
    Other Info
    Notebooks x 3

    Desktops x 5

    Towers x 4

Brink

Administrator
Administrator
mvp
Posts
22,708
#3
Thank you Ray. :)


My Computer

System One

  • OS
    64-bit Windows 10
    Computer type
    PC/Desktop
    System Manufacturer/Model Number
    Custom self built
    CPU
    Intel i7-3930K 3.2 Ghz (O/C to 4 Ghz)
    Motherboard
    ASRock X79 Extreme11
    Memory
    32 GB (8GBx4) G.SKILL DDR3 Quad PC3-19200 2400 MHz
    Graphics Card(s)
    ASUS ROG-STRIX-GTX1080TI-O11G-GAMING
    Sound Card
    SB Recon 3Di Integrated Chip
    Monitor(s) Displays
    3 x 27" Asus VE278Q
    Screen Resolution
    1920x1080
    Hard Drives
    256GB OCZ Vector
    6TB WD Black WD6001FZWX
    PSU
    OCZ Series Gold OCZZ1000M 1000W
    Case
    Corsair Air 740
    Cooling
    Corsair Hydro H115i
    Keyboard
    Logitech wireless K800
    Mouse
    Logitech MX Master
    Internet Speed
    100 Mb/s Download and 10 Mb/s Upload
    Browser
    Internet Explorer 11
    Antivirus
    Malwarebyte Anti-Malware Premium
    Other Info
    Lite-On iHBS212 12x BD Writer
    Creative F200 webcam
    Samsung CLX-3175FW Printer
    Linksys EA9500 Router
    Arris SB6190 Cable Modem
    APC SMART-UPS RT 1000 XL

iron2000

Member
Member
Posts
17
#4
If Secure Boot is on then Windows 8 is confirmed to be UEFI booted, right?

I just updated the BIOS and the startup changed from the usual ASUS logo to the Windows 8 logo, but in msinfo32 the BIOS mode is UEFI and Secure Boot is on.
And to add, my boot SSD is GPT.


My Computer

System One

  • OS
    Windows 8 Pro x64
    Computer type
    PC/Desktop
    CPU
    i5 3470
    Motherboard
    Asus P8H77-M Pro
    Memory
    8 GB
    Graphics Card(s)
    Asus GT430
    Sound Card
    Asus Xonar DX
    Hard Drives
    Intel 330 128 GB
    Seagate 500 GB
    WD Blue 1 TB
    PSU
    Seasonic 520W

Brink

Administrator
Administrator
mvp
Posts
22,708
#5
Hello iron,

That's correct. When it says that "BIOS mode" is UEFI, then your Windows 8 was installed with UEFI. Secure Boot is a feature of UEFI.

Hope this helps. :)


My Computer

System One

  • OS
    64-bit Windows 10
    Computer type
    PC/Desktop
    System Manufacturer/Model Number
    Custom self built
    CPU
    Intel i7-3930K 3.2 Ghz (O/C to 4 Ghz)
    Motherboard
    ASRock X79 Extreme11
    Memory
    32 GB (8GBx4) G.SKILL DDR3 Quad PC3-19200 2400 MHz
    Graphics Card(s)
    ASUS ROG-STRIX-GTX1080TI-O11G-GAMING
    Sound Card
    SB Recon 3Di Integrated Chip
    Monitor(s) Displays
    3 x 27" Asus VE278Q
    Screen Resolution
    1920x1080
    Hard Drives
    256GB OCZ Vector
    6TB WD Black WD6001FZWX
    PSU
    OCZ Series Gold OCZZ1000M 1000W
    Case
    Corsair Air 740
    Cooling
    Corsair Hydro H115i
    Keyboard
    Logitech wireless K800
    Mouse
    Logitech MX Master
    Internet Speed
    100 Mb/s Download and 10 Mb/s Upload
    Browser
    Internet Explorer 11
    Antivirus
    Malwarebyte Anti-Malware Premium
    Other Info
    Lite-On iHBS212 12x BD Writer
    Creative F200 webcam
    Samsung CLX-3175FW Printer
    Linksys EA9500 Router
    Arris SB6190 Cable Modem
    APC SMART-UPS RT 1000 XL

MilesAhead

Eclectician
VIP Member
Pro User
Posts
2,130
#6
So is the $64,000 question.. if W8 has secure boot on, then gets hosed... are all your bootable rescue CDs and USB keys useless? Or is there a basic strategy that still provides rootkit resistance while allowing system rescue?


My Computer

System One

  • OS
    Windows 8.0 x64
    Computer type
    Laptop
    System Manufacturer/Model Number
    Toshiba Satelite C55D-A Laptop
    CPU
    AMD EI 1200
    Memory
    4 gb DDR3
    Graphics Card(s)
    Raedon 340 MB dedicated Ram
    Monitor(s) Displays
    Built in
    Screen Resolution
    1366 x 768
    Hard Drives
    640 GB (spinner) Sata II
    Keyboard
    Built in
    Mouse
    Touch pad

Brink

Administrator
Administrator
mvp
Posts
22,708
#7
Last edited:

My Computer

System One

  • OS
    64-bit Windows 10
    Computer type
    PC/Desktop
    System Manufacturer/Model Number
    Custom self built
    CPU
    Intel i7-3930K 3.2 Ghz (O/C to 4 Ghz)
    Motherboard
    ASRock X79 Extreme11
    Memory
    32 GB (8GBx4) G.SKILL DDR3 Quad PC3-19200 2400 MHz
    Graphics Card(s)
    ASUS ROG-STRIX-GTX1080TI-O11G-GAMING
    Sound Card
    SB Recon 3Di Integrated Chip
    Monitor(s) Displays
    3 x 27" Asus VE278Q
    Screen Resolution
    1920x1080
    Hard Drives
    256GB OCZ Vector
    6TB WD Black WD6001FZWX
    PSU
    OCZ Series Gold OCZZ1000M 1000W
    Case
    Corsair Air 740
    Cooling
    Corsair Hydro H115i
    Keyboard
    Logitech wireless K800
    Mouse
    Logitech MX Master
    Internet Speed
    100 Mb/s Download and 10 Mb/s Upload
    Browser
    Internet Explorer 11
    Antivirus
    Malwarebyte Anti-Malware Premium
    Other Info
    Lite-On iHBS212 12x BD Writer
    Creative F200 webcam
    Samsung CLX-3175FW Printer
    Linksys EA9500 Router
    Arris SB6190 Cable Modem
    APC SMART-UPS RT 1000 XL

MilesAhead

Eclectician
VIP Member
Pro User
Posts
2,130
#8
Ah, sounds good. Thanks.


My Computer

System One

  • OS
    Windows 8.0 x64
    Computer type
    Laptop
    System Manufacturer/Model Number
    Toshiba Satelite C55D-A Laptop
    CPU
    AMD EI 1200
    Memory
    4 gb DDR3
    Graphics Card(s)
    Raedon 340 MB dedicated Ram
    Monitor(s) Displays
    Built in
    Screen Resolution
    1366 x 768
    Hard Drives
    640 GB (spinner) Sata II
    Keyboard
    Built in
    Mouse
    Touch pad

theog

VIP Member
VIP Member
Gold Member
Posts
5,591
#9
All bootable software using WinRE4 x64 will boot with Secure Boot ENABLED.

Last edited:

My Computer

System One

  • OS
    ME, XP,Vista,Win7,Win8,Win8.1
    Computer type
    PC/Desktop
    Other Info
    Notebooks x 3

    Desktops x 5

    Towers x 4

MilesAhead

Eclectician
VIP Member
Pro User
Posts
2,130
#10
@theog Thanks, that's good to know.


My Computer

System One

  • OS
    Windows 8.0 x64
    Computer type
    Laptop
    System Manufacturer/Model Number
    Toshiba Satelite C55D-A Laptop
    CPU
    AMD EI 1200
    Memory
    4 gb DDR3
    Graphics Card(s)
    Raedon 340 MB dedicated Ram
    Monitor(s) Displays
    Built in
    Screen Resolution
    1366 x 768
    Hard Drives
    640 GB (spinner) Sata II
    Keyboard
    Built in
    Mouse
    Touch pad
#11
Shawn this machine is "downgraded" form 8 to 7 do I need to check the BIOS for secure boot as a matter of course?


My Computer

System One

  • OS
    8 Pro desk 1 (SB) 7 Home desk 2 (IB) 8 Pro Lap 1
    Computer type
    PC/Desktop
    System Manufacturer/Model Number
    Own build X 2 Desk X 1 Lap X 2
    CPU
    i5 2500 & i5 3570K
    Motherboard
    Gigabyte GA_H67UD3H-B3 & Asus P8Z77-V
    Memory
    8GB (1333) 8GB 2400 set 1866
    Graphics Card(s)
    NVidia GTX 650 X 2
    Sound Card
    Xonar DG X 2
    Monitor(s) Displays
    Philips 24" (SB) Benq 24" (IB)
    Hard Drives
    Samsung 840 X 2 830 X 1
    PSU
    Corsair HX 650 & HX 1050
    Case
    Coolermaster Centurion 2 & HAF XM
    Cooling
    Air (SB) LC (IB)
    Keyboard
    M6980X X 2 (laser)M$ Sidewinder X4 & Sidewinder X6 (IB)
    Mouse
    Gigabyte M6980 X X 2 (laser)
    Internet Speed
    ADSL2
    Browser
    Google
    Antivirus
    Kaspersky ISS
    Other Info
    Two other machines Toshiba L550 Sat i5 CPU running 8GB RAM and Windows 8 Pro 64bit OS.
    Toshiba A200Celeron 4GB Win7 64bit

Brink

Administrator
Administrator
mvp
Posts
22,708
#12
Hello John,

It depends on if you installed Windows 7 with UEFI or legacy, and if you wanted secure boot enabled or not. :)


My Computer

System One

  • OS
    64-bit Windows 10
    Computer type
    PC/Desktop
    System Manufacturer/Model Number
    Custom self built
    CPU
    Intel i7-3930K 3.2 Ghz (O/C to 4 Ghz)
    Motherboard
    ASRock X79 Extreme11
    Memory
    32 GB (8GBx4) G.SKILL DDR3 Quad PC3-19200 2400 MHz
    Graphics Card(s)
    ASUS ROG-STRIX-GTX1080TI-O11G-GAMING
    Sound Card
    SB Recon 3Di Integrated Chip
    Monitor(s) Displays
    3 x 27" Asus VE278Q
    Screen Resolution
    1920x1080
    Hard Drives
    256GB OCZ Vector
    6TB WD Black WD6001FZWX
    PSU
    OCZ Series Gold OCZZ1000M 1000W
    Case
    Corsair Air 740
    Cooling
    Corsair Hydro H115i
    Keyboard
    Logitech wireless K800
    Mouse
    Logitech MX Master
    Internet Speed
    100 Mb/s Download and 10 Mb/s Upload
    Browser
    Internet Explorer 11
    Antivirus
    Malwarebyte Anti-Malware Premium
    Other Info
    Lite-On iHBS212 12x BD Writer
    Creative F200 webcam
    Samsung CLX-3175FW Printer
    Linksys EA9500 Router
    Arris SB6190 Cable Modem
    APC SMART-UPS RT 1000 XL
#13
Ok Shawn now I know the machine has EUFI but I don't know without a quick check - what the seller who installed the 7 on this machine actually set in the BIOS as I am reasonably familiar with the EUFI but this APTIO is not much like the Asus desktop I have with EUFI.

Now I just have to look up what secure boot is all about:)


My Computer

System One

  • OS
    8 Pro desk 1 (SB) 7 Home desk 2 (IB) 8 Pro Lap 1
    Computer type
    PC/Desktop
    System Manufacturer/Model Number
    Own build X 2 Desk X 1 Lap X 2
    CPU
    i5 2500 & i5 3570K
    Motherboard
    Gigabyte GA_H67UD3H-B3 & Asus P8Z77-V
    Memory
    8GB (1333) 8GB 2400 set 1866
    Graphics Card(s)
    NVidia GTX 650 X 2
    Sound Card
    Xonar DG X 2
    Monitor(s) Displays
    Philips 24" (SB) Benq 24" (IB)
    Hard Drives
    Samsung 840 X 2 830 X 1
    PSU
    Corsair HX 650 & HX 1050
    Case
    Coolermaster Centurion 2 & HAF XM
    Cooling
    Air (SB) LC (IB)
    Keyboard
    M6980X X 2 (laser)M$ Sidewinder X4 & Sidewinder X6 (IB)
    Mouse
    Gigabyte M6980 X X 2 (laser)
    Internet Speed
    ADSL2
    Browser
    Google
    Antivirus
    Kaspersky ISS
    Other Info
    Two other machines Toshiba L550 Sat i5 CPU running 8GB RAM and Windows 8 Pro 64bit OS.
    Toshiba A200Celeron 4GB Win7 64bit

Brink

Administrator
Administrator
mvp
Posts
22,708
#14
There's some good information about secure boot in the links at the top of the tutorial if you like. :)


My Computer

System One

  • OS
    64-bit Windows 10
    Computer type
    PC/Desktop
    System Manufacturer/Model Number
    Custom self built
    CPU
    Intel i7-3930K 3.2 Ghz (O/C to 4 Ghz)
    Motherboard
    ASRock X79 Extreme11
    Memory
    32 GB (8GBx4) G.SKILL DDR3 Quad PC3-19200 2400 MHz
    Graphics Card(s)
    ASUS ROG-STRIX-GTX1080TI-O11G-GAMING
    Sound Card
    SB Recon 3Di Integrated Chip
    Monitor(s) Displays
    3 x 27" Asus VE278Q
    Screen Resolution
    1920x1080
    Hard Drives
    256GB OCZ Vector
    6TB WD Black WD6001FZWX
    PSU
    OCZ Series Gold OCZZ1000M 1000W
    Case
    Corsair Air 740
    Cooling
    Corsair Hydro H115i
    Keyboard
    Logitech wireless K800
    Mouse
    Logitech MX Master
    Internet Speed
    100 Mb/s Download and 10 Mb/s Upload
    Browser
    Internet Explorer 11
    Antivirus
    Malwarebyte Anti-Malware Premium
    Other Info
    Lite-On iHBS212 12x BD Writer
    Creative F200 webcam
    Samsung CLX-3175FW Printer
    Linksys EA9500 Router
    Arris SB6190 Cable Modem
    APC SMART-UPS RT 1000 XL
#15
Thanks mate I shall look as a quick Google has given me a slight idea but expect your refs will be clearer.:)


My Computer

System One

  • OS
    8 Pro desk 1 (SB) 7 Home desk 2 (IB) 8 Pro Lap 1
    Computer type
    PC/Desktop
    System Manufacturer/Model Number
    Own build X 2 Desk X 1 Lap X 2
    CPU
    i5 2500 & i5 3570K
    Motherboard
    Gigabyte GA_H67UD3H-B3 & Asus P8Z77-V
    Memory
    8GB (1333) 8GB 2400 set 1866
    Graphics Card(s)
    NVidia GTX 650 X 2
    Sound Card
    Xonar DG X 2
    Monitor(s) Displays
    Philips 24" (SB) Benq 24" (IB)
    Hard Drives
    Samsung 840 X 2 830 X 1
    PSU
    Corsair HX 650 & HX 1050
    Case
    Coolermaster Centurion 2 & HAF XM
    Cooling
    Air (SB) LC (IB)
    Keyboard
    M6980X X 2 (laser)M$ Sidewinder X4 & Sidewinder X6 (IB)
    Mouse
    Gigabyte M6980 X X 2 (laser)
    Internet Speed
    ADSL2
    Browser
    Google
    Antivirus
    Kaspersky ISS
    Other Info
    Two other machines Toshiba L550 Sat i5 CPU running 8GB RAM and Windows 8 Pro 64bit OS.
    Toshiba A200Celeron 4GB Win7 64bit
