Solved Intel HD Graphics 2000/3000

XDleader555

New Member
Power User
Messages
253
Location
I'm not sure...
If it has the Yellow Icon you didn't use the Custom Certificate Installer. That automatically enables testing mode for you and installs the GfxTest.com Certificate to the Trusted Store.

If you are running a laptop, try my other thread.

And I'm uploading a mirror to mediafire right now.


My Computer

System One

  • OS
    Windows 8 Pro x64
    CPU
    Intel Core i5-2500k
    Motherboard
    ASRock z77 Extreme 4
    Memory
    Team Elite 8GB (4 x 2GB)
    Graphics Card(s)
    Intel HD Graphics 3000 & Nvidia GT 530
    Sound Card
    Realtek ALC892
    Screen Resolution
    1920x1080
    Hard Drives
    Western Digital Caviar Black 750 GB SATA III 7200 RPM
    PSU
    Antec NEO ECO 620C 620W
    Case
    NZXT GAMMA Classic Series
    Cooling
    Cooler Master Hyper 212 Plus
    Keyboard
    i-rocks RF-6570
    Mouse
    i-rocks RF-7550A
    Internet Speed
    17Mbps

kazaduel

Member
Member
Messages
21
If it has the Yellow Icon you didn't use the Custom Certificate Installer. That automatically enables testing mode for you and installs the GfxTest.com Certificate to the Trusted Store.

If you are running a laptop, try my other thread.

And I'm uploading a mirror to mediafire right now.

There is no yellow icon, and I just tried the other thread with the mobile ones? It ran through but I see no difference. I have two graphics family drivers however?


My Computer

System One

  • OS
    windows 8 release preview
    System Manufacturer/Model
    Dell
    CPU
    Sandy Bridge i5 2.30ghz
    Memory
    8gb

MKhairy048

Member
Member
Messages
17
If it has the Yellow Icon you didn't use the Custom Certificate Installer. That automatically enables testing mode for you and installs the GfxTest.com Certificate to the Trusted Store.

If you are running a laptop, try my other thread.

And I'm uploading a mirror to mediafire right now.

There is no yellow icon, and I just tried the other thread with the mobile ones? It ran through but I see no difference. I have two graphics family drivers however?
difference for what !!

what had you expected for this driver to do :D


My Computer

System One

  • OS
    windows 8

MKhairy048

Member
Member
Messages
17
to me I need this driver to make NVidia card works on optimus as provided driver make panic blue screen

now my notebook n5110 have updated fully working drivers :)


My Computer

System One

  • OS
    windows 8

kazaduel

Member
Member
Messages
21
If it has the Yellow Icon you didn't use the Custom Certificate Installer. That automatically enables testing mode for you and installs the GfxTest.com Certificate to the Trusted Store.

If you are running a laptop, try my other thread.

And I'm uploading a mirror to mediafire right now.

There is no yellow icon, and I just tried the other thread with the mobile ones? It ran through but I see no difference. I have two graphics family drivers however?
difference for what !!

what had you expected for this driver to do :D
I expected this driver to make my laptop monitor work again lol. it only works in safe mode and when booting up.


My Computer

System One

  • OS
    windows 8 release preview
    System Manufacturer/Model
    Dell
    CPU
    Sandy Bridge i5 2.30ghz
    Memory
    8gb

XDleader555

New Member
Power User
Messages
253
Location
I'm not sure...
The Mobile Drivers are different then these ones... o-o
You only have to try them if you are having trouble with the ones in this thread.
Try uninstalling and try not installing through safe mode.
If you have an external screen hook that up and try to install through that.


My Computer

System One

  • OS
    Windows 8 Pro x64
    CPU
    Intel Core i5-2500k
    Motherboard
    ASRock z77 Extreme 4
    Memory
    Team Elite 8GB (4 x 2GB)
    Graphics Card(s)
    Intel HD Graphics 3000 & Nvidia GT 530
    Sound Card
    Realtek ALC892
    Screen Resolution
    1920x1080
    Hard Drives
    Western Digital Caviar Black 750 GB SATA III 7200 RPM
    PSU
    Antec NEO ECO 620C 620W
    Case
    NZXT GAMMA Classic Series
    Cooling
    Cooler Master Hyper 212 Plus
    Keyboard
    i-rocks RF-6570
    Mouse
    i-rocks RF-7550A
    Internet Speed
    17Mbps

kazaduel

Member
Member
Messages
21
I havnt been installing in safemode, and I have been using an external this entire time =P. I now tried running the mobile ones and it comes up with "the driver is not validaed and stuff like that. I have installed the certificate installer. I have tried every driver on here, and the other thread, some running all the way through and others not but none fixing the issue.


My Computer

System One

  • OS
    windows 8 release preview
    System Manufacturer/Model
    Dell
    CPU
    Sandy Bridge i5 2.30ghz
    Memory
    8gb

MKhairy048

Member
Member
Messages
17
my friend also having problem with laptop screen on windows 8

waiting him to let him test the new driver
hope it work for him

the latest intel driver works good under windows 7

hope it works under windows 8 also


My Computer

System One

  • OS
    windows 8

kazaduel

Member
Member
Messages
21
well im giving up for now, hopefully an official fix come soon. =/


My Computer

System One

  • OS
    windows 8 release preview
    System Manufacturer/Model
    Dell
    CPU
    Sandy Bridge i5 2.30ghz
    Memory
    8gb

Miles360x

Member
Member
Messages
11
Firstly install this: Driver

Then install your descret videocard driver (Nvidia or ATI). Download driver for them from dell sile.

both drivers were installed correctly, but problem is still the same - only external monitor works. I only have Intel HD graphic card in my laptop (without nVidia Optimus).

Same problem here: http://www.eightforums.com/installation-setup/4034-windows-8-dell-n5110-black-screen.html

I have 100% same problem on VOSTRO 3350, Intel HD 3000, no NVidia card also.
Have you managed to fix it?

Same problem,
Still no fix?

I too have a Vostro 3550


My Computer

System One

  • OS
    Windows 8.1 Pro
    Computer type
    PC/Desktop
    CPU
    i7-3930k
    Motherboard
    Sabertooth X79
    Memory
    Dominator Platinum 4x4GB DDR3-1866
    Graphics Card(s)
    GTX 780
    Monitor(s) Displays
    VG248QE, VG248QE, VG248QE
    Screen Resolution
    5760x1080
    Hard Drives
    Intel 520 120GB SSD
    1TB WD Black
    1TB WD Green
    1TB WD External USB 3.0
    PSU
    AX1200
    Case
    Corsair 800D
    Cooling
    Corsair H100
    Keyboard
    Razer BlackWidow
    Mouse
    Razer Abyssus
    Internet Speed
    50Mbps - 10Mbps
    Browser
    Chrome
    Antivirus
    None, Hack Me!

Miles360x

Member
Member
Messages
11
I have Dell Inspiron N5110.
And i've done all like this:

1. Install Win8
2. Go to Programms -> Enable Net framework 2.0 and 3.0
3. Go to Updates Centre. Make 3rd option in settings (Download and make choose what to install)
4. Dont UPDATE NVIDIA and Intel Graphics Drivers from Update Center
5. Install this Driver
6. Download Nvidia drivers from Dell and install
7. Reboot the pc.

I followed this with my Vostro 3550 and the same problem is reoccuring.


My Computer

System One

  • OS
    Windows 8.1 Pro
    Computer type
    PC/Desktop
    CPU
    i7-3930k
    Motherboard
    Sabertooth X79
    Memory
    Dominator Platinum 4x4GB DDR3-1866
    Graphics Card(s)
    GTX 780
    Monitor(s) Displays
    VG248QE, VG248QE, VG248QE
    Screen Resolution
    5760x1080
    Hard Drives
    Intel 520 120GB SSD
    1TB WD Black
    1TB WD Green
    1TB WD External USB 3.0
    PSU
    AX1200
    Case
    Corsair 800D
    Cooling
    Corsair H100
    Keyboard
    Razer BlackWidow
    Mouse
    Razer Abyssus
    Internet Speed
    50Mbps - 10Mbps
    Browser
    Chrome
    Antivirus
    None, Hack Me!

MakavelliJrw

New Member
Messages
5
Nvm, I figured it out myself. (Go to bottom of post for modified setup downloads.)

How It was done:
Part 1
Downloaded the latest drivers. Extract the files to a folder. Go to C:\Users\Username\Downloads\Win7Vista_64_152250\Graphics and open up "igdlh64.inf"

Found this section
Code:
;
; Driver information
;


[Manufacturer]
%Intel% = IntelGfx, NTamd64[U][B].5.1, NTamd64.6.0, NTamd64.6.2 [/B][/U]


[U][B][IntelGfx.NTamd64.5.1]
; no install on XP


[IntelGfx.NTamd64.6.2]
; no install on Win8
[/B][/U]

[IntelGfx.NTamd64[U][B].6.0[/B][/U]]
%iILKGM0% = iILKM0, PCI\VEN_8086&DEV_0046
%iILKG0% = iILKD0, PCI\VEN_8086&DEV_0042
%iSNBGM1% = iSNBM0, PCI\VEN_8086&DEV_0106
%iSNBGD1% = iSNBD0, PCI\VEN_8086&DEV_0102
%iSNBGM2% = iSNBM0, PCI\VEN_8086&DEV_0116
%iSNBGD2% = iSNBD0, PCI\VEN_8086&DEV_0112
%iSNBGM2P% = iSNBM0, PCI\VEN_8086&DEV_0126
%iSNBGD2P% = iSNBD0, PCI\VEN_8086&DEV_0122
%iSNBGD3% = iSNBD0, PCI\VEN_8086&DEV_010A
and I deleted everything until "NTamd64"
Code:
;
;
; Driver information
;


[Manufacturer]
%Intel%   = Intel.Mfg, NTamd64


[Intel.Mfg.NTamd64]
%iILKGM0% = iILKM0, PCI\VEN_8086&DEV_0046
%iILKG0% = iILKD0, PCI\VEN_8086&DEV_0042
%iSNBGM1% = iSNBM0, PCI\VEN_8086&DEV_0106
%iSNBGD1% = iSNBD0, PCI\VEN_8086&DEV_0102
%iSNBGM2% = iSNBM0, PCI\VEN_8086&DEV_0116
%iSNBGD2% = iSNBD0, PCI\VEN_8086&DEV_0112
%iSNBGM2P% = iSNBM0, PCI\VEN_8086&DEV_0126
%iSNBGD2P% = iSNBD0, PCI\VEN_8086&DEV_0122
%iSNBGD3% = iSNBD0, PCI\VEN_8086&DEV_010A

Then go back to the installation folder and run setup.exe

Part 2

After the setup go to windows update and change the settings to:
"Check for updates but let me choose whether to download and install them"
Reboot with the modified .inf installed and check for updates. Then right click the Intel update and select "Hide Update"

Hope this helps ppl who have windows 8 and want acceleration :D

~~~~~~~~~~~~~EDIT~~~~~~~~~~~~~~~~~~~~
If you are reeeeaally lazy you can download the modified setup here.
Make sure to follow Part 2 or your driver will be deleted.
UNSIGNED drivers will not work in Windows Consumer Preview.

It says that the 8.15.10.2598 Driver is a higher version. Ignore If you want.
Also, I lag in MineCraft with
8.15.10.2622. Stay on 8.15.10.2598 for speed.

~~~~~~ SIGNED Drivers ~~~~~~
To install the signed drivers run the custom certificate installer I made
which is based off of barcher's Post.

All thanks go to barcher for his work around in Consumer Preview.
MediaFire Mirrors are nice and compressed for faster downloading :D

-Custom Certificate Installer- Chrome users may experience a malicious warning. It is false. Virus Total
MediaFireMirror
RapidShareMirror
DropBoxMirror

-Version 8.15.10.2509- SIGNED
64bit MediaFireMirror
32bit MediaFireMirror
64bit RapidShareMirror
32bit RapidShareMirror
64bit DropBoxMirror
32bit DropBoxMirror

-Version 8.15.10.2598 With OpenCL- SIGNED
64bit MediaFireMirror
32bit MediaFireMirror
64bit RapidShareMirror
32bit RapidShareMirror
64bit DropBoxMirror
32bit DropBoxMirror

-Version 8.15.10.2622- SIGNED
64bit MediaFireMirror
32bit MediaFireMirror
64bit RapidShareMirror
32bit RapidShareMirror
64bit DropBoxMirror
32bit DropBoxMirror

~~~~~~ UNSIGNED Drivers ~~~~~~
-Version 8.15.10.2509- UNSIGNED
64bit Win7Vista_64_152250_UNSIGNED.zip
32bit Win7Vista_152250_UNSIGNED.zip

-Version 8.15.10.2598 With OpenCL- UNSIGNED
64bit WinVista7_64_8.15.10.2598_UNSIGNED.zip
32bit WinVista7_8.15.10.2598_UNSIGNED.zip

-Version 8.15.10.2622- UNSIGNED64bit Win7Vista_64_152254_UNSIGNED.zip
32bit Win7Vista_152254_UNSIGNED.zip



Ok I have a problem!! Every .zip file that I download from Mediafire has a problem extracting anything

the error.jpg

I have tried to download the files from Rapidshare (which is very very slow) and they alays come up with an error at the very end. I was wondering if you could either upload something new or send me a link of the 2509 through Skydrive?? OR if I should just use the obile extraction drivers??

Also I was wondering if all I had to do in this process was:

1. Download and upload the Custom Certificate Install
2. Go to the Device Manager and manually try to upgrade the "Intel(R) HD Graphics Family" driver by manually picking the .inf file from your custom downloads
3. Restart the computer and the monitor should be working as it should then in 1366 x 768 with the accelerated graphics??


My Computer

System One

  • OS
    Windows 8 Consumer Preview
    System Manufacturer/Model
    Dell Inspiron N5110
    Memory
    6 GB
    Graphics Card(s)
    Intel HD 3000

XDleader555

New Member
Power User
Messages
253
Location
I'm not sure...
All you have to do is run the Custom certificate Installer and then run the setup. I tried to keep it as simple as possible. No manual driver installation needed.

It doesn't seem like Windows 8 likes my compressing. Try 7zip or another program which supports LZMA compression. It works fine when I decompress it with 7zip


My Computer

System One

  • OS
    Windows 8 Pro x64
    CPU
    Intel Core i5-2500k
    Motherboard
    ASRock z77 Extreme 4
    Memory
    Team Elite 8GB (4 x 2GB)
    Graphics Card(s)
    Intel HD Graphics 3000 & Nvidia GT 530
    Sound Card
    Realtek ALC892
    Screen Resolution
    1920x1080
    Hard Drives
    Western Digital Caviar Black 750 GB SATA III 7200 RPM
    PSU
    Antec NEO ECO 620C 620W
    Case
    NZXT GAMMA Classic Series
    Cooling
    Cooler Master Hyper 212 Plus
    Keyboard
    i-rocks RF-6570
    Mouse
    i-rocks RF-7550A
    Internet Speed
    17Mbps

arnop

New Member
Messages
7
I have Dell Inspiron N5110.
And i've done all like this:

1. Install Win8
2. Go to Programms -> Enable Net framework 2.0 and 3.0
3. Go to Updates Centre. Make 3rd option in settings (Download and make choose what to install)
4. Dont UPDATE NVIDIA and Intel Graphics Drivers from Update Center
5. Install this Driver
6. Download Nvidia drivers from Dell and install
7. Reboot the pc.

I followed this with my Vostro 3550 and the same problem is reoccuring.

Still NO FIX on VOSTRO 3350. I tried every possibility posted on this forum thread. I really appreciate help from this forum members, but still - no fix on Vostro 3350, i5-2410m, Intel HD 3000 for now.


My Computer

System One

  • OS
    W8
    System Manufacturer/Model
    DELL
    CPU
    i5
    Motherboard
    -
    Memory
    4g
    Graphics Card(s)
    intell hd 3000

MKhairy048

Member
Member
Messages
17
I think we need to take a look on regestiry to see why windows doesn't identify lvds connector

I will compaire my reg and my friend one and see


My Computer

System One

  • OS
    windows 8

barchar

New Member
Messages
3
In response to the people several pages back who could not run inf2cat, I am afraid that as it turns out that does not come with visual studio, you have to also download the Window Driver Kit from Windows Driver Kit (WDK) 8 Consumer Preview, honestly in total this all comes to like 3 or 4 gigs of stuff to download so just using the signed drivers uploaded by XDLeader

also I am not positive that inf2cat is added to the PATH variable so you may have to use the full path when you run it. It is typically located at C:\Program Files (x86)\Windows Kits\8.0\bin\x86 note that it is in the x86 folder even on 64bit computers

I apologize that it took so long for me to respond to this error


My Computer

System One

  • OS
    Windows 8

oliver92

New Member
Messages
2
Hi, I have a similar problem with the graphic card driver, I`m running Windows 8 CP 64 bit on an external hard drive, and I cant install the Intel HD Graphics 3000 driver, I`m stuck with the Windows Basic one instead. And I cant change the resolution from anything but 1024x768.
I`ve tried all the methods you`ve provided but I don't seem to be able to install it. Which is really wired, since when I installed the Windows 8 CP on the internal hard drive, the same driver installed natively.
I just want to be able to change to the native resolution my lap top has, which is 1300x768.
Is there a way to do it?
Maybe force the resolution to change, or install the driver in a different way...

Tnx in advance :)


My Computer

System One

  • OS
    Windows 8
    System Manufacturer/Model
    Lenovo Y560
    CPU
    Intel i5 CPU M460 2.53 GHz 2.53 GHz
    Memory
    6 GB
    Graphics Card(s)
    Intel HD Graphics 3000

MakavelliJrw

New Member
Messages
5
All you have to do is run the Custom certificate Installer and then run the setup. I tried to keep it as simple as possible. No manual driver installation needed.

It doesn't seem like Windows 8 likes my compressing. Try 7zip or another program which supports LZMA compression. It works fine when I decompress it with 7zip


I tried all 3 downloads as you said and the screen was still blank. I had to revert back to Windows Default driver..

Is there anything that I could do or could I just install the mobile 4x drivers??


My Computer

System One

  • OS
    Windows 8 Consumer Preview
    System Manufacturer/Model
    Dell Inspiron N5110
    Memory
    6 GB
    Graphics Card(s)
    Intel HD 3000

XDleader555

New Member
Power User
Messages
253
Location
I'm not sure...
In response to the people several pages back who could not run inf2cat, I am afraid that as it turns out that does not come with visual studio, you have to also download the Window Driver Kit from Windows Driver Kit (WDK) 8 Consumer Preview, honestly in total this all comes to like 3 or 4 gigs of stuff to download so just using the signed drivers uploaded by XDLeader

also I am not positive that inf2cat is added to the PATH variable so you may have to use the full path when you run it. It is typically located at C:\Program Files (x86)\Windows Kits\8.0\bin\x86 note that it is in the x86 folder even on 64bit computers

I apologize that it took so long for me to respond to this error
It's alright barchar, I made a custom Certificate installer with a pre made security catalog that is based off your instructions (Credit was given) so they don't have to go through all the trouble downloading this and that.

EDIT: Whoops, didn't see the last sentence. And Inf2cat and signtool is not added to the path, so you will have to add them manually or specify the path.


My Computer

System One

  • OS
    Windows 8 Pro x64
    CPU
    Intel Core i5-2500k
    Motherboard
    ASRock z77 Extreme 4
    Memory
    Team Elite 8GB (4 x 2GB)
    Graphics Card(s)
    Intel HD Graphics 3000 & Nvidia GT 530
    Sound Card
    Realtek ALC892
    Screen Resolution
    1920x1080
    Hard Drives
    Western Digital Caviar Black 750 GB SATA III 7200 RPM
    PSU
    Antec NEO ECO 620C 620W
    Case
    NZXT GAMMA Classic Series
    Cooling
    Cooler Master Hyper 212 Plus
    Keyboard
    i-rocks RF-6570
    Mouse
    i-rocks RF-7550A
    Internet Speed
    17Mbps

barchar

New Member
Messages
3
Signtool was in my path when I opened the developer command prompt but I think the dev command prompt runs a script that adds some more things to the path


My Computer

System One

  • OS
    Windows 8
Top
